JAKA Ai 18

Category JAKA All-In-One

Payload 18 kg | Reach 1073 mm

Product Features:

The JAKA Ai collaborative robot 18 is flexible, fast, and has excellent repeatability (±0.03mm).
It has an incredibly high weight-payload ratio, and is able to handle its 18kg payload in a working radius of 1073mm. As such, it’s a great cobot for lifting and moving heavy parts and products, machine tending, palletizing, vision picking, polishing, inspection, more.
JAKA Ai 18 can be integrated dynamically, seamlessly adapted for various tasks, all monitored for precision and efficacy by visual feedback. Palletizing, packaging, light and heavy-duty production lines, handling household appliances, and many other tasks are safely within the JAKA Ai 18’s purview.

JAKA Ai 18 Parameters

Size	67×57×45 mm (L×W×H)
Communication Interface	Ethernet Interfaces (TCP/IP Protocol)
Trigger Mode	Soft trigger
PX	500 w
Resolution	2592(H) ×1944(V)
FPS	24 FPS mm
Focus	8 mm

Payload	18 kg
Weight (W cable)	35 kg
Working Radius	1073 mm
Repeatability	±0.03mm
Axis	6
Programming	Graphical \| Visual
Teach Pendant	MT(PAD/Mobile)APP
Collaborative operation	In compliance with GB 11291.1-2011
Certifications	CR, CE, 15066
Robot	Workscope	Max Speed
Joint 1	±360°	120°/s
Joint 2	-85°，+265°	120°/s
Joint 3	±175°	180°/s
Joint 4	-85°，+265°	180°/s
Joint 5	±360°	180°/s
Joint 6	±360°	180°/s
Max Speed	/	3.5 m/s
Rated Power	600 W
Temperature Range	0-50℃
IP Specification	IP54
Tool I/O Power	24V
Tool I/O Size	M8
Base Diameter	129 mm
Installation	At any angle
Material	Aluminum, PC
Tool I/O	Digital input 2/Digital output 2/Analog input 1
Cable Length	6 m
Package Size	770×510×505(mm) (L×W×H)
