JAKA Ai 3

Category JAKA All-In-One

Payload 3 kg | Reach 626 mm

Product Features:

With 3 kg payload and working radius of 626 mm, JAKA Ai 3 is small-environ cobot for complex tasks such as flexible assembly, inspection, or testing.
Despite its smaller size, it packs all the key JAKA Ai series features – graphic programming, visual feedback and wireless teach – making it ideal for use across automotive, medical devices, 3C electronics, and a whole host of other industries.
The JAKA Ai 3 has flexible dismount options, making it possible to easily mount vertically too, at 45-degree angle positions, or even upside-down on a ceiling. Moreover, no fences are required.

JAKA Ai 3 Parameters

Size	67×57×45 mm (L×W×H)
Communication Interface	Ethernet Interfaces (TCP/IP Protocol)
Trigger Mode	Soft trigger
PX	500 w
Resolution	2592(H) ×1944(V)
FPS	24 FPS mm
Focus	8 mm

Payload	3 kg
Weight (W cable)	12 kg
Working Radius	626 mm
Repeatability	±0.02mm
Axis	6
Programming	Graphical I Visual
Teach Pendant	MT(PAD/Mobile)APP
Collaborative operation	In compliance with GB 11291.1-2011
Certifications	CR, CE, 15066
Robot	Workscope	Max Speed
Joint 1	±360°	180°/s
Joint 2	-85°，+265°	180°/s
Joint 3	±175°	180°/s
Joint 4	-85°，+265°	220°/s
Joint 5	±360°	220°/s
Joint 6	±360°	220°/s
Max Speed	/	1.5 m/s
Rated Power	150 W
Temperature Range	0-50℃
IP Specification	IP54
Tool I/O Power	24V
Tool I/O Size	M8
Base Diameter	129 mm
Installation	At any angle
Material	Aluminum, PC
Tool I/O	Digital input 2/Digital output 2/Analog input 1
Cable Length	6 m
Package Size	460×375×365(mm) (L×W×H)
