JAKA Ai 5

Category JAKA All-In-One

Payload 5 kg | Reach 954 mm

Product Features:

The JAKA Ai 5 can handle a 5kg payload, and has a working radius of 954mm. With its excellent manoeuvrability, complicated automated tasks like flexible assembly, inspection and testing are no problem at all.
The JAKA Ai 5 shines in many industries, but is particularly useful in logistics and manufacturing; palletizing, working on automobile and auto parts production lines, helping make medical devices, 3C electronics and more.
With a decent payload-weight ratio, the JAKA Ai 5 can be mounted in a variety of positions and places – vertically, horizontally, at sloped angles or even upside down. And no more fences required!

JAKA Ai 5 Parameters

Size	67×57×45 mm (L×W×H)
Communication Interface	Ethernet Interfaces (TCP/IP Protocol)
Trigger Mode	Soft trigger
PX	500 w
Resolution	2592(H) ×1944(V)
FPS	24 FPS mm
Focus	8 mm

Payload	5 kg
Weight (W cable)	23 kg
Working Radius	954 mm
Repeatability	±0.02mm
Axis	6
Programming	Graphical \| Visual
Teach Pendant	MT(PAD/Mobile)APP
Collaborative operation	In compliance with GB 11291.1-2011
Certifications	CR, CE, 15066
Robot	Workscope	Max Speed
Joint 1	±360°	180°/s
Joint 2	-85°，+265°	180°/s
Joint 3	±175°	180°/s
Joint 4	-85°，+265°	180°/s
Joint 5	±360°	180°/s
Joint 6	±360°	180°/s
Max Speed	/	3 m/s
Rated Power	350 W
Temperature Range	0-50℃
IP Specification	IP54
Tool I/O Power	24V
Tool I/O Size	M8
Base Diameter	129 mm
Installation	At any angle
Material	Aluminum, PC
Tool I/O	Digital input 2/Digital output 2/Analog input 1
Cable Length	6 m
Package Size	460×375×365(mm) (L×W×H)
